Dr. Uwe Griebner

uwe.griebner(at)mbi-berlin.de
+49 30 6392 1457

C2: Solid State Light Sources
Haus C, 2.22

Position

Project Coordinator 4.1: Implementation of Lasers and Measuring Techniques

Research

Development of advanced ultrashort pulse lasers, amplifiers, and parametric devices operating in the near- and mid-IR wavelength ranges including components and complete systems for direct implementation within other projects at MBI.

An example is the development of novel CPA laser sources emitting around 2 µm wavelength. This laser system operating at kilohertz repetition rate will serve as driver for OPCPA in the mid-IR. Figure (a) shows the simulated bifurcation diagram of a Ho:YLF regenerative amplifier (RA) at a 1 kHz repetition rate and 24 round trips indicating the most interesting operation regimes, i.e., stable double-pulsing (yellow coded bar) and the single-energy regime (green coded bar) beyond the final bifurcation point (BP final). Based on our model the RA is designed for operation in the single-energy regime beyond BPfinal. The measured complete RA bifurcation diagram of the re-designed RA at 1 kHz and 24 round trips is presented in Fig. (b). It agrees well with our numerical simulations [Fig. (a)]. Only the predicted multi-pulsing between 20 and 30 W pump power is less pronounced in the experiment. The highest pulse energy of 12 mJ can be extracted in the stable double-pulsing regime in the upper bifurcation branch (yellow coded bar), however at 0.5 kHz, the half of the repetition rate. BPfinal appears at a pump power of 47 W and denotes the transition to the single-energy regime where any multi-stabilities and chaotic behavior have been overcome. The extracted RA pulse energy of 9.7 mJ is the by far highest reported for 2-µm RAs operating in the single-energy regime. Taking into account the applied pump power of 50 W, the extraction efficiency is as high as 19.5%. Performing the transition from the stable double-pulsing to the single-energy regime, the RA’s pulse-to-pulse stability is further improved with a rms value <0.5%. Figure (c) shows the corresponding pulse stability measurement in the vicinity of BPfinal and beyond in the single-energy regime (green coded bar).

Curriculum vitae

since 1992 Max Born Institute for Nonlinear Optics and Short Pulse Spectroscopy, Berlin, Germany, staff scientist and project coordinator.

1993 - 1996 Ph.D. thesis at the Optical Institute, Technical University Berlin, Germany, with Prof. Horst Weber,
Title of thesis: Fiber bundle lasers with high average power,

1989 - 1992 Institute of Nonlinear Optics and Short Pulse Spectroscopy, Berlin, Germany, staff scientist,

1986 - 1989 Institute of Mechanics, Chemnitz, Germany, staff scientist,

1981 - 1986 Diploma degree in Physics; Physics Department, University of Jena, Germany,
Title of thesis: Characterization of lattice distorsions in LiF crystals,

MBI Publikationen

  1. Pulse shaping in a midwave-IR OPCPA for multi-μJ few-cycle pulse generation at 12 μm via DFG

    M. Bock, L. von Grafenstein, P. Fuertjes, D. Ueberschaer, M. Duda, O. Novák, N. Abrosimov, U. Griebner

     Optics Express 31 (2023) 14096-14108
  2. 44-fs pulse generation at 2.05 µm from a SESAM mode-locked Tm:GdScO3 laser

    N. Zhang, Q. Song, J. Zhou, J. Liu, S. Liu, H. Zhang, X. Xu, Y. Xue, J. Xu, W. Chen, Y. Zhao, U. Griebner, V. Petrov

     Optics Letters 48 (2023) 510-513
  3. Tm,Ho:Ca(Gd,Lu)AlO4 crystals: Polarized spectroscopy and laser operation

    Z. Pan, P. Loiko, J. M. Serres, H. Yuan, Y. Wang, L. Wang, Y. Zhao, R. M. Solé, M. Aguiló, F. Díaz, P. Camy, W. Chen, U. Griebner, V. Petrov, X. Mateos

     Journal of Luminescence 257 (2023) 119638/1-11
  4. Excitation transfer from Cr2+ to Fe2+ ions in co-doped ZnSe as a pumping scheme for infrared solid-state lasers

    J. W. Tomm, G. Steinmeyer, P. Fuertjes, U. Griebner, T. Elsaesser

     Journal of Electronic Materials Online (2023)
  5. Efficient electronic excitation transfer via phonon-assisted dipole-dipole coupling in Fe2+∶Cr2+:ZnSe

    G. Steinmeyer, J. W. Tomm, P. Fuertjes, U. Griebner, S. S. Balabanov, T. Elsaesser

     Physical Review Applied 19 (2023) 054043/1-11
  6. Tm,Ho:Ca(Gd,Lu)AlO4 crystals: Crystal growth, structure refinement and Judd-Ofelt analysis

    Z. Pan, P. Loiko, S. Slimi, H. Yuan, Y. Wang, Y. Zhao, P. Camy, E. Dunina, A. Kornienko, L. Fomicheva, L. Wang, U. Griebner, V. Petrov, R. M. Solé, F. Díaz, M. Aguiló , X. Mateos

     Journal of Luminescence 246 (2022) 118828/1-10
  7. Diode-pumped and tunable laser operation of Tm,Ho-codoped modified CNGG-type disordered crystals

    Z. Pan, P. Loiko, Y. Wang, Y. Zhao, H. Yuana, J. M. Serres, W. Chen, L. Wang, U. Griebner, V. Petrov, M. Aguiló, F. Díaz, X. Mateos

     Proceedings of SPIE 11980 (2022) 198003/1-6
  8. Sub-100 fs SWCNT-SA mode-locked Tm,Ho:LCLNGG laser

    Z. Pan, L. Wang, W. Chen, J. E. Bae, F. Rotermund, Y. Wang, Y. Zhao, P. Loiko, X. Mateos, U. Griebner, V. Petrov

     Proceedings of SPIE 11980 (2022) 1198002/1-6
  9. Cr:ZnS-based soliton self-frequency shifted signal generation for a tunable sub-100 fs MWIR OPCPA

    P. Fuertjes, L. von Grafenstein, C. Mei, M. Bock, U. Griebner, T. Elsaesser

     Optics Express 30 (2022) 5142-5150
  10. Kinetics of excitation transfer from Cr2+ to Fe2+ ions in co-doped ZnSe

    P. Fuertjes, J. W. Tomm, U. Griebner, G. Steinmeyer, S. S. Balabanov, E. M. Gavrishchuk, T. Elsaesser

     Optics Letters 47 (2022) 2129-2131
